| General |
| Type |
Workstation |
| Product Form Factor |
Small form factor |
| Embedded Security |
Trusted Platform Module (TPM 2.0) Security Chip |
| Localization |
Language: English / region: United States |
|
| Processor / Chipset |
| CPU |
Intel Core i7 (8th Gen) 8700 / 3.2 GHz |
| Max Turbo Speed |
4.6 GHz |
| Number of Cores |
6-core |
| CPU Qty |
1 |
| Max CPU Qty |
1 |
| Chipset Type |
Intel C246 |
|
| Cache Memory |
| Installed Size |
12 MB |
| Cache Per Processor |
12 MB |
|
| RAM |
| Installed Size |
8 GB / 64 GB (max) |
| Technology |
DDR4 SDRAM - non-ECC |
| Effective Memory Speed |
2666 MHz |
| Rated Memory Speed |
2666 MHz |
| Form Factor |
DIMM 288-pin |
| Slots |
4 (total) / 3 (empty) |
| Features |
Unbuffered, mixing of different types of memory modules is not supported |
| Configuration Features |
1 x 8 GB |
|
| Hard Drive |
| Type |
SSD - M.2 |
| Capacity |
1 x 256 GB |
| Interface Type |
PCI Express |
| Features |
TCG Opal Encryption |
|
| Storage Controller |
| Type |
1 x RAID |
| Controller Interface Type |
SATA 6Gb/s |
| Channel Qty |
4 |
| RAID Level |
RAID 0, RAID 1 |
|
| Optical Storage |
|
|
| Card Reader |
| Type |
Card reader |
| Supported Flash Memory Cards |
SD Memory Card |
|
| |
| Graphics Controller |
| Graphics Processor |
Intel UHD Graphics 630 |
| Video Interfaces |
HDMI, DisplayPort |
|
| Audio Output |
| Compliant Standards |
High Definition Audio |
|
| Input Device |
|
|
| Keyboard |
|
|
| Mouse |
| Technology |
Optical |
| Interface |
USB |
|
| Networking |
| Ethernet Controller |
Intel I219-LM |
| Data Link Protocol |
Ethernet, Fast Ethernet, Gigabit Ethernet |
| Features |
Wake on LAN (WoL) |
|
| Expansion / Connectivity |
| Bays |
1 (total) / 1 (free) x external 5.25" Slim Line ¦ 1 (total) / 1 (free) x internal 3.5" ¦ 1 (total) / 1 (free) x internal 2.5" |
| Slots |
1 (total) / 1 (free) x PCIe 3.0 x16 - half-length, full-height ¦ 1 (total) / 1 (free) x PCIe 3.0 x1 - full-length, full-height ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 - half-length, full-height (x4 mode) ¦ 1 (total) / 0 (free) x M.2 Card |
| Interfaces |
4 x USB 3.1 Gen 1 (2 front, 2 rear) ¦ 2 x USB 3.1 Gen 2 (2 in front) ¦ 1 x microphone (1 in front) ¦ 1 x headphones/microphone (1 in front) ¦ 1 x USB-C 3.1 Gen 1 (1 in front) ¦ 1 x LAN (Gigabit Ethernet) ¦ 2 x USB 2.0 ¦ 2 x DisplayPort ¦ 1 x HDMI |
|
| Miscellaneous |
| Included Accessories |
Vertical stand |
| Theft/Intrusion Protection |
Security lock slot (cable lock sold separately), padlock loop, cable lock, chassis intrusion switch |
| Security Slot Type |
Kensington security slot |
| Compliant Standards |
RoHS, GREENGUARD |
| |
|
|
| Power |
| Device Type |
Power supply |
| Nominal Voltage |
AC 120/230 V (50/60 Hz) |
| Power Provided |
260 Watt |
| 80 PLUS Certification |
80 PLUS Platinum |
| Efficiency |
92% |
|
| Operating System / Software |
| OS Provided |
Windows 10 Pro 64-bit Edition |
|
| Environmental Standards |
| ENERGY STAR Certified |
Yes |
| ENERGY STAR Version |
7.0 |
|
| Manufacturer Warranty |
| Service & Support |
Limited warranty - 3 years Manufacture |
|
| Dimensions & Weight |
| Width |
3.6 in |
| Depth |
12 in |
| Height |
13.5 in |
| Weight |
13.23 lbs |
|
