520 MB/s Maximum Read Transfer Rate - 256-bit Encryption Standard



General Information

Manufacturer:   Kingston Technology Company
Manufacturer Part Number:   SUV500MS/240G
Manufacturer Website Address:   www.kingston.com
Brand Name:   Kingston
Product Model:   UV500
Product Name:   UV500 SSD
Marketing Information:

An encrypted solution for every user.

Kingston's UV500 family of solid-state drives dramatically improves the responsiveness of your existing system with incredible boot, loading and transfer times compared to mechanical hard drives. Powered by a Marvell Dean controller combined with 3D NAND Flash for read and write speeds up to 520MB/s and 500MB/s , this SSD is 10X faster than a traditional hard drive for better performance, ultra-responsive multi-tasking and an overall faster system. UV500 provides end-to-end data protection, supports 256-bit AES hardware-based encryption and TCG Opal 2.0 security management solutions.

More reliable and durable than a hard drive, UV500 is built with NAND Flash semiconductor memory. There are no moving parts, making it far less likely to fail than a mechanical hard drive. It is also cooler and quieter, and its shock and vibration resistance makes it ideal for notebooks and other mobile computing devices.

UV500 is available in multiple capacities from 120GB-960GB, so you can buy one to use as a boot drive, or take advantage of the larger capacities to store videos, photos and host your most frequently used applications.

Product Type:   Solid State Drive

Technical Information

Storage Capacity:   240 GB
Encryption Standard:   256-bit

Drive Performance

Maximum Read Transfer Rate:   520 MB/s
Maximum Write Transfer Rate:   500 MB/s

Network & Communication

Wireless LAN:   No

Interfaces/Ports

Drive Interface:   SATA
Drive Interface Standard:   SATA/600

Power Description

Operating Power Consumption:   2.32 W

Physical Characteristics

Drive Type:   Internal
Form Factor:   mSATA
Height:   0.19" (4.85 mm)
Width:   1.18" (29.85 mm)
Depth:   2" (50.80 mm)
Weight (Approximate):   6.7 g

Miscellaneous

Device Supported:   Notebook
Device Supported:   Desktop PC

Warranty

Limited Warranty:   5 Years Manufacture
